I want to have my first floor lights all automated by a central control box (star wiring arrangement, already laid to allow this). At the heart of this I need a relay control PCB which should be at least 16way. The day job gives me the skills to design such a PCB, but there are some off-the-shelf options and a variety of prices and they would come with CE marking of equally variable legitimacy. I could power the whle thing from a mains plug in which case it would be outside of the scope of the Sparkie's signoff, but I want his blessing and he's keen to see a CE mark on it. I want to control the PCB with either a Raspberry Pi Zero or ESP32 which I am happy configuring and running a local webserver from. The Raspberry Pi would allow a USB connection to the relay PCB (as would some ESP32 boards), but I would prefer to have something less protocol stack sensitive like I2C or UART. Does anyone have a good recommendation of suitable relay PCBs. I have seen things ranging from White Wing £175 to Amazon / Aliexpress <£11. The main thing I want to be able to trust is the relays themselves since that's where the mains is. I think all the PCBs have optical isolators, but I wouldn't handle the RPi / ESP32 when it's got mains anyway.

Thanks Craig. A difficulty I have is that the frame I am using is designed around a 44mm thick door and consequently the recesses are 47mm deep. There is no room to fit a bead in with a triple glazing unit. What I was thinking of doing was adding a timber piece (dark brown ) to the back of the frame that extends over the edge of the glazing panel and effectively forms the bead. Unlike pins in a normal bead scenario which are loaded perpendicular to their length, any fixings in that additional piece would be loaded along their length, so pins would pull out. I could use screws, but they would end up visible which I don't want (oak finish). The clips seem like a good solution since the bead ends up just being cosmetic as I understand it. I realise I could extend the frame by gluing timber on which is no wider that the frame already is and then use a conventional timber bead, but that would mean I would have to extend the frame more. I expect a suitable bead would be at least 15mm whereas I can have a much thinner back piece (dark brown) if it's only cosmetic and clips are doing the work of holding the panel. It's shown below as 12mm, but could go thinner.

@craig Have you come across these clips before? Any thoughts?

I don't want to get flamed for it, but some manufacturers say that chambers (mini ones) don't need to be installed with a fall. I install them with a fall though. In my experience (limited) the chamber bottom and rim are parallel so you can check wall at the top.

I'm making a custom door with sidelights and want to use a secure clip glazing system to hold the glazing panels in place. The panels are 44mm thick triple glazed ones, so that's a bit unusual for the clip systems I think. I have seen two systems online: GT Securi-Clip [link] - apparently PAS 24 Reddiseals Easy-Clip [link] - now discontinued unfortunately Has anyone any experience with these? They seem to top out at 28mm glazing thickness, but I see no reason I couldn't use a 28mm one offset the correct amount as long as I supported the glazing unit on suitably wide packers.

Osma (Wavin) advice on protecting shallow pipes. I've put 100mm over the pipe crown everywhere, so can use slabs where less than 600mm and just backfill (inc. 40mm stone) elsewhere.

It is a tiny amount and I think there is always going to be a little bit of liquid left against the seal by the nature of the fact that the MAC8E's pipe section is a narrower ID than the Spigot's OD. Like so much of this game, it's really annoying when you've worked hard to get it right and then the tolerances conspire against you. I think you're right, time to crack open a beer.

By measuring the height (107mm) above tile to the underside of the MAC-8E's 'trumpet spigot flange' and based on a crude measurement of the MAC-8E drawing's 'trumpet spigot flange' O.D. (136mm) I get that the spigot height of this toilet is actually 175mm (107 + (136/2)) not the 180mm it's supposed to be. That's the main route of my problem. The tiling is also likely a tad thinner than expected, but the spigot dimension is the main issue.

I guess hunting around for a toilet with a 190mm spigot height (or 185mm minimum).

Actually, thinking about it there is often going to be some water there since the toilet spigot is larger diameter than the pipe section

May mean I have some waste water permanently sat in the connector against the seal to the toilet pan. Isn't that a concern?

I haven't drilled any holes for the toilet screws yet so that wouldn't be an issue. I do have some spare tiles. Are you thinking I could create a low platform for the toilet to sit on?

I'm using a McAlpine CON8E and it connects up nicely except my soil pipe is too high relative to the tiled surface meaning the connector's pipe section doesn't have a fall. In fact it slopes slightly the wrong way. If I raise the toilet up on 5mm packers, this pipe section is level. Ideally I'd want a fall of about 1:40, which would mean having the toilet 10mm above the tile. I can't change the height of the soil pipe as it is all boxed in so I'm wondering what to do? I think the spigot on the toilet is lower than it says in its dimension drawing (180mm) and the tile build-up is thinner. I've attached some pictures of the situation and then a single picture of it with 5mm packers under the toilet.

Probably still less wasteful than whizzing hot water round a circulation system all day long

The concern with uninsulated cold pipes is condensation forming on them. I think a 15mm pipe is something like a litre per 10m of run. A shower at 6L/min would clear 10m of pipe in 10s. I've even wondered about the benefits of a circulatory hot system Vs just filling the toilet cistern from the hot supply. The cistern fill would clear the pipe of the cold water before the basin tap get turned on. Insulating hot pipes for between uses is pointless in my mind. Others may have experience to the contrary though. Also, regs require it.

Loads of colours available to add to white cement. White cement is more expensive (2x I think) but small difference Vs labour costs. If achieving the colour using an additive rather than sand, check how consistent it will be. The brickie's labourer may vary the dose and that could create banding. There is an expensive new college building I see in Cambridge and it's a dogs dinner due to this issue I think. You can influence the colour a lot with choice of sand and that should be more consistent as long as everyone understands. I'd be cautious of going the lime route. Fewer brickies have experience with it and it can be less tolerant (e.g. temperature). In the right hands it's great and looks brilliant though.

It's really a struggle to maintain 1:100 with a couple of turns. I've wondered about sending the (remaining) furthest downpipe (at 27m) on that run into a channel drain going along the edge of the house. That runs at the surface and you can get a 110mm end cap. That would buy me about 40mm if the channel was laid with a 1:100 fall or 80mm if laid level. 80mm would allow the remaining 22m to fall at (425 - 110 - 25) : 22000 = 1:76. A channel drain here is a bit random though.

I was thinking the other day that a poor tiler can make expensive tiles look cheap, a good tiler can make expensive tiles look expensive but a great tiler can make cheap tiles look expensive. Hard to be sure, but from the picture the tiles themselves look fine.

If I have a stub and rocker off the rest bend before the long pipe (or stubs either side), it should provide some flexibility to tune the angles and position. That raises the number of seals from 2 (rest bend connected directly to gully and long pipe) to 6.

I'm using a type with a concrete top mould on which I don't think can rotate

I need to turn 90 degrees from my bottle gully without using an inspection chamber for the turn and see two main options for it: (a) use a 45 degree bend on the bottle gully and then a second 45 bend before the long pipe run (~5m). (b) use a rest bend either directly on the bottle gully or after a coupler and short length of pipe (will depend on trench position). Both should be roddable since the bottle gully can be rodded and there is an Inspection Chamber (I.C.) at the end of the long pipe (~5m). Can't you rod through a rest bend? If so, I lean towards option (b). (b) is also cheaper as I have a spare rest bend. What do others think? For full disclosure, the I.C. is a 4D960 shallow one and has two S/S 45 bends on it as it is at the corner of the house so the pipe turns. All these pipes will be paved over.

I'm a little disappointed to end up with Bottle Gullies rather than rest bends due to levels. I suspect Bottle Gullies could be a breeding ground for mosquitoes.

For long straight runs, socketed pipes are useful though and have fewer seals. I've gone with Osma fittings and pipes. A pipe and coupler works out about £3 more than a socketed Floplast pipe. I asked and Floplast didn't recommend using the socket of a pipe as one of the sockets of a rocker pipe.

I have Osma rest bends which have an invert 290+50=340mm below top of socket. Clearance to house makes this run about 20m, call it 21m which would be a 350mm drop at 1:60. If I have the 250mm chamber 50mm below the 450mm chamber's invert (600mm bgl), that would be a depth of 650mm. It's not a compliant depth for that 250mm chamber, but BCO was OK with a junction so I can just bury the chamber under a removable slab. The invert at the rest bend would be 650 - 350 = 300mm bgl so the rest bend's socket will stick out of the ground. I'll paint that black. Should work, but have to check fall to STP to confirm. Top of pipe at the rest bend will be 190mm bgl, falling to 190 + (8,000/60) = 323mm at the turn. The rainwater pipe it needs to cross will have an invert depth of about 175 + (5,000/100) = 225mm or 175 + (5,000/80) = 238mm at this point, so 100mm or 85mm clearance between pipes. Rainwater pipe invert after 20m needs to be 425mm and can start at 175mm, so may be 1:80. Osma rest bend:

You'd hope. Osma in general does seem well made but certainly carries a premium.
